Illustrated Anatomical Segmentectomy for Lung Cancer

1.3.3 Left Upper Lobe
1.3.3.1 Upper Division Artery
1. A 1+2 [R.apicodorsalis]
(a) A 1+2 a [Rm.apicalis]
(b) A 1+2 b [Rm.dorsalis]
(c) A 1+2 c [Rm.horizontalis]
2. A 3 [R.ventralis]
(a) A 3 a [Rm.lateralis]
(b) A 3 b [Rm.medialis]
(c) A 3 c [Rm.superior]
1.3.3.2 Lingular Division Artery
1. A 4 [R.lingualis superior]
(a) A 4 a [Rm.lateralis]
(b) A 4 b [Rm.medialis]
2. A 5 [R.lingualis inferior]
(a) A 5 a [Rm.superior]
(b) A 5 b [Rm.inferior]
1.3.4 Lower Lobes
1. A 6 [R.superior]
(a) A 6 a [Rm.superior]
(b) A 6 b [Rm.lateralis]
(c) A 6 c [Rm.medialis]
2. A * [R.subsuperior]
3. A 7 [R.mediobasalis] (only right side)
(a) A 7 a [Rm.dorsalis]
(b) A 7 b [Rm.ventralis]
4. A 8 [R.ventrobasalis]
(a) A 8 a [Rm.lateralis]
(b) A 8 b [Rm.basalis]
5. A 9 [R.laterobasalis]
(a) A 9 a [Rm.lateralis]
(b) A 9 b [Rm.basalis]
6. A 10 [R.dorsobasalis]
(a) A 10 a [Rm.dorsalis]
(b) A 10 b [Rm.lateralis]
(c) A 10 c [Rm.medialis]
1.4 Nomenclature of Segmental
and Subsegmental Vein
1.4.1 Right Upper Lobe
1. V 1 (V.apicalis)
(a) V 1 a: between S 1 a and S 1 b
(b) V 1 b: between S 1 b and S 3 b
2. V 2 (V.dorsalis)
(a) V 2 a: between S 1 a and S 2 a
(b) V 2 b: between S 2 a and S 2 b
(c) V 2 c: between S 2 b and S 3 a
(d) V 2 t: below S 2 a
3. V 3 (V.ventralis)
(a) V 3 a: between S 3 a and S 3 b
(b) V 3 b: below S 3 b
(c) V 3 c between S3bi and S3bii
4. Central vein: V 2 a+V 2 b+V 2 c(+V 3 a)
1.4.2 Right Middle Lobe
1. V 4 (V.media.lateralis)
(a) V 4 a: between S 4 a and S 4 b
(b) V 4 b: between S 4 b and S 5 b
2. V 5 (V.media.medialis)
(a) V 5 a: between S 5 a and S 5 b
(b) V 5 b: below S 5 b
1.4.3 Left Upper Lobe
1. V 1+2 (V.apicodorsalis)
(a) V 1+2 a: between S 1+2 a and S 3 c
(b) V 1+2 b: between S 1+2 a and S 1+2 b
(c) V 1+2 c: between S 1+2 b and S 1+2 c
(d) V 1+2 d: between S 1+2 c and S 3 a
2. V 3 (V.ventralis)
(a) V 3 a: between S 3 a and S 3 b
(b) V 3 b: between S 3 b and S 4 b
(c) V 3 c: between S 3 b and S 3 c
3. V 4 (V.lingualis superior)
(a) V 4 a: between S 4 a and S 4 b
(b) V 4 b: between S 4 b and S 5 a
4. V 5 (V.lingualis inferior)
(a) V 5 a: between S 5 a and S 5 b
(b) V 5 b: below S 5 b
1.4.4 Lower Lobes
1. V 6 (V.superior)
(a) V 6 a: between S 6 a and S 6 b+c
(b) V 6 b: between S6b and S6c, and between S6
and S8+9
(c) V 6 c: between S6c and S10a (or S7a only in the
right side)
2. V 7 (V.mediobasalis) (only right side)
(a) V 7 a: between S 7 a and S 7 b
(b) V 7 b: between S 7 b and S 8 b
